Instructions:

2.     Full bed surface is made of USA Electrolytic wood with X-ray cassette.

3.     Trendelenburg/reverse-trendelenburg, height adjustment, can be reached by foot pedal easily.

4.     Four wheel braking system, steering system, 200mm diameter castors reach mobility easy and convenient.

5.     Fowler position is reached by gas spring.

6.     Knee section manual control by hand crank.

7.     Ergonomic push handles.

8.     Frames with red rubber strip, beauty and anticollision.

9.     Four wheel braking system and steering system reach mobility easily and convenient.

10.  Stailness steel siderails, or aluminum alloy siderails.

Material:

1.     The frame is cold rolled steel with coating by twice electrostatic spray

2.     Once injection PP undercarriage, PP siderails, PP plateform, anticollision, easy to clean.

Technical Specifications:
  Size: 2100*800*630-930mm
   Backrest max upward angle: 90^o
  Footrest max upward angle: 45^o
  Trendelenburg:18^o
  Anti-trendelenburg:18^o
Standard Accessories: IV pole, 3‵‵thickness mattress Optional
