Instructions:

1.     Double hydraulic oil pump from USA power-packer brand of Actuant supply stable power source for hydraulic hospital stretcher.

2.      Back section X-ray available with X-ray cassette.

Trendelenburg/reverse-trendelenburg, height adjustment, can be reached by foot pedal easily.

3.      Four wheel braking system, steering system, 150mm diameter castors reach mobility easy and convenient.

4.      Fowler position is reached by gas spring.

5.      Knee section manual control by hand crank.

6.      Ergonomic push handles.

7.      Frames with red rubber strip, beauty and anticollision.

Four wheel braking system and steering system reach mobility easily and convenient

Material:

  Main material: X-ray permeable plastic bed board, stainless steel side rail, steel frame, hydraulic pumps, plastic chassis cover and metal chassis.

Technical Specifications:

   Bed board dimension: 1,750 x 620mm.

  Size: 2100*852* 835mm-600mm
  Backrest max upward angle: 60^o
  Footrest max upward angle: 40^o
  Height adjustment: 835mm-600mm

   Trendelenburg:13^o Anti-trendelenburg:13^o

   Packing:1.12CBM/PC   N.W:90kgs

Standard Accessories:

   IV pole, mattress
